The
YSP-1000 advanced digital design incorporates digital
amplifiers that power 42 speaker drivers with a total
of 120 Watts of highly efficient power.
7 CINEMA DSP PROGRAMS, DOLBY DIGITAL AND DTS
Yamaha’s acclaimed CINEMA DSP technology recreates thrilling
and realistic surround sound in your room. 7 CINEMA DSP
programs are available on the YSP-1000, which is also
compatible with Dolby Digital, DTS, Dolby Pro Logic II
and DTS Neo:6 surround sound formats.
COMPATIBLE
DECODING FORMATS
7
CINEMA DSP PROGRAMS
Dolby
Digital
DTS Digital Surround
Dolby Pro-Logic
Dolby Pro Logic II Music
Dolby Pro Logic II Movie
Dolby Pro Logic II Game
DTS Neo:6 (Music)
DTS Neo:6 (Cinema)
MUSIC
Concert
Hall
Music Video
Jazz Club
MOVIE
Spectacle
Sci-Fi
Adventure
SPORTS
Sports
MAIN
SPECIFICATIONS
Speakers
Section
1-5/8"
x 40 drivers
4-3/8" x 2 woofers
Digital
Amplifier
120
W total power:
2 W x 40 + 20 W x 2
Dimensions
(W x H x D)
40-9/16"
x 7-5/8" x 4-5/8"
1,030 x 194 x 118 mm
Weight
28.7
lbs.; 13 kg
The
YSP-1000 rear panel offers 2 optical/1 coaxial digital
and 2 analog audio input terminals, and 2 component video
and 3 composite video output terminals, subwoofer output
terminal, IR port, and RS-232C interface.
SPM-K1
Optional Wall Hanging Bracket
YST-FSW100
Recommended
Slim Subwoofer for YSP-1000 and YSP-800
The YSYT-FSW100 is available in silver or black
finish.
